Description
Specification:
| Model |
Speedy Bee VTX-DVR
|
|
| DVR | Video in |
CVBS@1Vp-p 75Ω
|
| Encoder |
MJPEG@AVI
|
|
| Resolution |
VGA ( 640 x 480 ) @ 30fps ( NTSC ) / 25 fps ( PAL )
|
|
| Audio |
Built-in MIC
|
|
| Micro SD Card |
Max 32G
|
|
| VTX | Frequency Channel |
5.8G 48CH
|
| Output Power |
25mW / 200mW / 600mW
|
|
| Video Input Impedance |
75 Ohm
|
|
| Antenna Connector | MMCX | |
| Power in |
DC 7-26V
|
|
| Working Current |
DC 9V @Max 450mA
|
|
| Power out |
DC 5V @Max 250mA
|
|
| Net Weight |
7.5 g (without antenna)
|
|
| Dimension |
36mm*36mm @30.5 × 30.5 M3 holes
|
|
Click here to download the manual: VTX-DVR-manual.pdf
Package included:
1 X VTX-DVR
1 X MMCX antenna
1 X MMCX to SMA Cable
1 X 1.0mm 6pin Cable
1 X Set of screws
