Description
Runcam Micro Swift 3 V2 4:3 600TVL CCD Mini FPV Camera Joystick/ UART Control Switchable OSD Configuration
Description:
Brand name: RunCam
Model: Micro Swift 3
Model: Micro Swift 3
Image Sensor: 1/3" SONY Super HAD II CCD
Horizontal Resolution: 600TVL
Lens: 2.1mm (M8) FOV160° , 2.3mm(M8) FOV 145° (Optional)
Signal System: PAL / NTSC
Integrated OSD: Yes
One Touch Scene Setting: Personal / Lightrax / Outdoor / Indoor / Cloudy / Twilight
S/N Ratio: >60dB (AGC OFF)
Electronic Shutter Speed: PAL: 1/50~100,000; NTSC: 1/60~100,000
Auto Gain Control (AGC): Yes
Min. Illumination: 0.01Lux@1.2F
WDR: D-WDR
DNR: 2DNR
Day/Night: Color/Auto/B&W
Menu Control: Joystick Control / UART Control Switchable
Power: DC 5-36V
Current: 60mA@12V / 120mA@5V
Net Weight: 6g(M8)
Dimensions: 19mm*19mm*18mm
Features:
* Vivid Scene Setting, Joystick Control/ UART Control Switchable
* Global Shutter NO Jello
RunCam Micro Swift 3 FPV Camera manual, click here
Package Included:
1x RunCam Micro Swift 3 Camera
1x 1928 ABS bracket
1x Set of screws
1x 6pin FPV silicone cable
1x Manual
