Description
RCINPOWER GTS V2 1207 5000/6000KV 3-4S 7500KV 2-3S Brushless Motor for RC Drone FPV Racing
Specification:
Brand name: RCINPOWER
Item name: GTS V2 1207
KV: 5000/6000/7500KV(Optional)
No. of Cells (Lipo): 3-4S @ 5000/6000KV;
2-3S @ 7500KV
Version: CW Screw Thread
2-3S @ 7500KV
Version: CW Screw Thread
Configuration: 12N14P
Stator Diameter: 12mm
Stator Length: 7mm
Shaft Diameter: 1.5mm(2mm inside)
Idle Current(10V): 1.3A @ 5000/6000KV ; 1A @7500KV
Max. Con. Power (5S): 250W @5000KV ; 285W @6000KV
Max. Con. Power (180S): 250W @7500KV ;
Max. Con. Power (180S): 250W @7500KV ;
Internal Resistance: 120mΩ @5000KV; 100mΩ @ 6000KV ; 110mΩ @ 7500KV
Max. Current(5s): 15A @ 5000KV
Max. Current(5s): 17A @ 6000KV
Max. Current(30s): 20A @ 7500KV
Motor Dimension(Dia*Len):21.3×27.6mm
Weight: 6.4g
Max. Current(5s): 17A @ 6000KV
Max. Current(30s): 20A @ 7500KV
Motor Dimension(Dia*Len):21.3×27.6mm
Weight: 6.4g
Package Included:
1 x GTS V2 1207 Brushless Motor
