Description
Description:
Brand: Racerstar
Item: 3650 Motor
Waterproof Level: Splash-proof
Features:
– 4 pole 12 slot hi-torque motor design
– CNC machined 6061 T6 billet aluminum heatsink can
– High purity copper windings maximizes efficiency
– High RPM ABEC 5 oversized bearings
– Universal fit, fits all 1/10 brushless cars; multi-mounting system for M3 screws
– Precision balanced rotor, smoothness for best reliability and maxium RPM
– Stator- super thin (0.35mm) laminations
– Removalbe/replaceable rotor
– Precision engineered for maxium energy coversion
Specification:
Watts: 900
Max Voltage: 8.4V(5900KV), 9.6V(5200KV), 12V(4300KV), 13V(3900KV), 16V(3100KV), 22V(2300KV), 24V(2050KV)
Max Amps: 107A(5900KV), 94A(5200KV), 74A(4300KV), 69A(3900KV), 56A(3100KV), 41A(2300KV), 38A(2050KV)
Rotor Poles: 4
Max RPM: 50000
Length: 50mm
Diameters: 36mm
Weight: About 180g
Shaft: 3.17mm
Length of Extend Shaft: 15mm
Connector: 4.0mm Gold
Note:
This motor usually works with 60A ESC.
For more information, please click here.
Package Included:
1 x Motor
