Description
Description:
Brand: Racerstar
Item: 2440 Brushless Motor
Waterproof Level: Splash-proof
Specification:
KV: 6080/4600/4000KV
Watts: 400
Max Voltage: 8.4V(6080KV), 10.8V(4600KV), 12.6V(4000KV)
Max Amps: 47A(6080KV), 37A(4600KV), 32A(4000KV)
KV: 6080/4600/4000KV
Watts: 400
Max Voltage: 8.4V(6080KV), 10.8V(4600KV), 12.6V(4000KV)
Max Amps: 47A(6080KV), 37A(4600KV), 32A(4000KV)
IO: 3.2(6080KV), 2.6(4600KV), 2.2A(4000KV)
Resistance: 0.003, 0.006, 0.012
Max RPM: 50000
Length: 40mm
Diameters: 24mm
Shaft: ￠2.3mm
Lenght of extend shaft: 12mm
Connector: 3.5mm gold
Resistance: 0.003, 0.006, 0.012
Max RPM: 50000
Length: 40mm
Diameters: 24mm
Shaft: ￠2.3mm
Lenght of extend shaft: 12mm
Connector: 3.5mm gold
Poles: 4
Weight: 68g
Application: 1:18 1:16 On/Off-road/ Truck /Monster
Feature:
4 Pole 12 Slot Hi-torque Motor Design
CNC Machined 6061 T6 Billet Aluminum Heatsink Can
High Purity Copper Windings Maximizes Efficiency
High RPM ABEC5 Oversized Bearings
Universal fit,fits all 1/18, 1/16 brushless cars-multi-mounting system for M2.5 screws
Precision balanced rotor,smoothness for best reliability and maximum RPM
CNC Machined 6061 T6 Billet Aluminum Heatsink Can
High Purity Copper Windings Maximizes Efficiency
High RPM ABEC5 Oversized Bearings
Universal fit,fits all 1/18, 1/16 brushless cars-multi-mounting system for M2.5 screws
Precision balanced rotor,smoothness for best reliability and maximum RPM
Stator – Super Thin (0.35mm) Laminations
Removable/Replaceable Rotor
Precision Engineered for Maximum Energy Conversion
Removable/Replaceable Rotor
Precision Engineered for Maximum Energy Conversion
Package Included:
1 x Motor
