Racerstar 2435 Waterproof Brushless Sensorless Motor 4500/4800KV 25A ESC For 1/16 1/18 RC Car
Description:
Brand: Racerstar
Item Name: Brushless Motor
KV: 4500/4800KV
Resist: 0.0057Ω
Max Voltage:<12.6V
IO:2.0A
Max Amps:24A
Outer Diameter/Length: 24mm /35mm
Diameter of the Shaft: 2mm
Length of extend shaft: 12mm
Poles: 4
Weight: 63g
Application: 1:18, 1:16 On/Off-road/ Truck /Monster
Feature:
4 Pole 12 Slot Hi-torque Motor Design
CNC Machined 6061 T6 Billet Aluminum Heatsink Can
High Purity Copper Windings Maximizes Efficiency
High RPM ABEC5 Oversized Bearings
Universal fit,fits all 1/8 brushless cars-multi-mounting system for M3 screws
Precision balanced rotor,smoothness for best reliability and maximum RPM
Stator – Super Thin (0.35mm) Laminations
Removable/Replaceable Rotor
Precision Engineered for Maximum Energy Conversion
ESC Specification:
Cont./Burst Current: 25A/100A
Suitable Car: 1/18,1/16 RC Car
Suitable Brushless Motor: ≥12T
Resistance:0.004ohm
Battery: 2 cells Lipo; 4~6 cells NiMH
BEC Output: 5V/2A (analog mode)
Dimension: 25*30*14.5mm
For manual, please click here
For ESC program card, please click
Package Included:
1 x Motor
1 x ESC
1 X Manual
