Omnibus F4 Corner Nano Flight Controller With ICM20608 Damping Box IMU Build In OSD Current Sensor
Description:
Item name: Omnibus F4 Corner Nano Flight Controller
STM32 F405 MCU, Runs Betaflight firmware(supported from v3.2)
ICM20608 Via SPI Bus in damping box.
20x20mm Mounting holes
27x27mm
Supports Lipo direct plug in (2-4S)
Supports 5V 1A BEC output(Buck)
STM32 controls OSD chip over SPI in DMA mode(Betaflight OSD)
Build in Current sensor
Build in LC filter for Camera power(max 800ma)
Auto invert/N-invert serial port for sbus/ibus/dsm
Package included:
1 x Omnibus F4 Corner Nano Flight Controller
