Description
iRangeX Fli14+ Flysky Receiver AFHDS-2A w/ RSSI OSD Double Antenna 500m Distance for FS-i6 FS-i6S
Description:
Brand Name: iRangeX
Item Name: Fli14+ RX
Channel: 14
Protocol: AFHDS-2A
2.4G Mode: The second generation of an enhanced version of the automatic FM digital system
Antenna Length: 70mm (Dual Antennas)
Input Power: 4.0-6.5V DC
Weight: Only 1.7g
Size: 25mm*15mm*5mm
Color: Black
Signal Output: IBUS
RSSI Output: Channel14
No ground interference ( Transmitting and receiving 1 m from the ground): >500m
Features:
– Customized for Betaflight
– RSSI Display Via OSD without any hack compatible with all Flysky AFHDS-2A protocol transmitter
– Telemetry output: RSSI & RX Battery
– Support RSSI Via Channel14(Aux10 in Betaflight)
– Best for FPV Racing drone
– Compatible with FS-i4, FS-i6, FS-I6X, FS-i6S, FS-i10, FS-iT4S, Eachine I6, Turnigy I6S, Turnigy Evolution
Binding Procedure:
1. Power for the Fli14 Receiver while press and holding the bind button
2. The LED will blinking fast , this indicates the receiver is in binding mode
3. Get the Flysky transmitter into binding mode , the LED on the receiver will getting to be solid and this indicates binding successfully
Receiver Configuration:
RSSI:
Package Included:
1 x Fli14+ RX
