Description
iFlight SucceX F4 Mini V2 35A 2-6S Dshot1200 4 In 1 Brushless ESC for RC Drone FPV Racing
PRODUCT DESCRIPTION
The latest developed BLHeli-32-bit 35A 4-in-1 mini ESC is highly integrated, greatly reduced from the standard size, features excellent performance, supports 6S, the target is iFlight-BL32-4IN1.Supporting Dshot, Multishot, Oneshot, etc. The soldering pad is semi-extended, save more room but solid.
Specifications:
MCU:STM32F051
Current Sensor: no
Input:2-6s lipo
Installing Hole: 20x20mm, M2
Target: iFlight-BL32-4IN1
Constant:35Amps
Burst:45Amps
Dimensions:31*31mm(including the power pads)
Mounting Holes:20*20mm
Features:
STM32F051 MCU , fast resonding;
Added additional capacitors to reduce power noise;
32bit ESC with BLHELI32 firmware
Supports 2-6S lipo input
4PWM input
Compact size 31*31mm
Super-lightweight xxg
Supports Oneshot125, Oneshot42, Multishot, Dshot150, Dshot300, Dshot600, Dshot1200
Package included:
1 x SucceX Mini V2 35A 2-6S 4 in 1 ESC
1 x Cable Set
