Description
Holybro Kakute F7 V1.5 Flight Controller & 65A BL_32 Tekko32F3 Metal 4in1 ESC 4-6S Stack Combo for RC Drone
Specification:
Brand Name: Holybro
Item Name: F7 Flight Controller & 65A 4 in 1 ESC Stack
Kakute F7 V1.5 Flight Controller ( Manual )
Brand name: Holybro
Item name: Kakute F7 V1.5
MCU: STM32F745 32-bit processor
IMU: MPU6000 (SPI)
Barometer: BMP280
Current Sensor: Approximately 130 amps maximum measurable value
Current Sensor: Approximately 130 amps maximum measurable value
USB VCP Driver (all UARTs usable simultaneously; USB does not take up a UART)
6 hardware UARTS (UART1,2,3,4,6,7)
All UARTS support hardware inversion. SBUS, SmartPort, and other inverted protocols work on any UART without “uninvert hack”.
Supports serial receivers (SBUS, iBus, Spektrum, Crossfire) only. PPM and PWM receivers are not supported.
TF card for Blackbox logging
Dimensions: 35x41x7mm (includes foam-mounted gyro board in height)
Mounting Holes: Standard 30.5mm square to center of holes
Weight: 8g
Tekko32F3 Metal 4in1 ESC ( Manual)
Brand Name: Holybro
Model: Tekko32F3 Metal
F3(M4 Core) MCU, Runs BLHELI32 firmware, the MCU works at 108Mhz
The 4in1 has onboard analog current sensor, and TLM function(then no current reading over TLM)
Using metal case mosfet for better Heat dissipation
Supports Lipo 4-6S
Ext. cap needed for 6s (470uf 35v for 6s usage.)
Size:42 x 42 mm
Mounting holes:30.5×30.5mm
Weight: 12g
Notice:
The air flow is very import if you want to run this 4in1 in high current.
The input cable(from lipo to 4in1), should be good soldered, and at least 12AWG
Features:
– The 4in1 has onboard analog current sensor, and TLM function(then no current reading over TLM)
– Using metal case mosfet for better Heat dissipation
– BLheli_32 firmware, support Oneshot, Multishot, Dshot150, DShot300, DShot600 and DShot1200
Package Included:
1x Kakute F7 flight controller
1x Tekko32 F3 Metal 4in1 ESC
1x 470uF 35V Electrolytic Capacitor
1x 8pin to 8pin 1mm pitch 65mm Cable
1x 8pin to 8pin 1mm pitch 25mm Cable
