Description
Description:
Item Brand:HGLRC-FLIPSKY
Item name:FSESC 200A 60V
Product Size:79.5*58.5*23mm(included the heat sink)
Packaging size:205*140*40mm
Product Weight:About 210g
Packaging Weight:Approx 400g
The Wiring diagram,please click here
Product Weight:About 210g
Packaging Weight:Approx 400g
The Wiring diagram,please click here
Advanced Features:
1. ESC can reach continuous 200A current
2. Preserve Bluetooth module and RF module connections
3. Aluminum anodized Heat sink with fins design for better heat dissipation
4. Compact size with heatsink: 58x80x15mm (L*W*D)
5. PCB layers: 8layers, thickness: 3oz/layer, total 24 oz thickness
Spec:
Hardware: V 6.6
Firmware: VESC_default_no_hw_limits
Voltage: 8V – 60V (Safe for 3S to 12S LiPo, Voltage spikes may not exceed 60V)
Current: Continuous 200A , Burst current 800A
5V 1.5A output for external electronics
3.3V 1A output for external electronics
Modes: DC, BLDC, FOC (sinusoidal)
Supported sensors: ABI, HALL, AS5047
Waterproof level:IP67
Package Included:
1X FSECS 200A + Heatsink
1X Micro USB
1X VESC Sensor Wire
1X Manual
