GEPRC PHANTOM Toothpick Freestyle 2-4S FPV Racing Drone BNF/PNP F4 OSD 12A ESC 1103 Motor
PHANTOM is a super mini Freestyle Quad,2.5inch propeller and GR1103 8000kv motors with 3S 300mAh battery, The flight experience is like a 5-inch propeller quad. Freestyle training quad. You will be like it.
Specification:
Brand name: GEPRC
Item name: PHANTOM Toothpick Freestyle 2-4S FPV Racing Drone
FC:STM32F411
ESC:12A(BLheli_S)
Motor: GEPRC GEP-GR1103 8000KV(3S 300mAh)
Wheelbase: 125mm
Propeller: 65mm or 2.5inch
VTX:5.8g 200mW
Camera:Caddx EOS2
Weight: 51g (without battery)
STABLE F411 Micro System:
STABLE F411 Flight Controller(16*16mm)
MCU: STM32F411
IMU: MPU6000 gyro/accelerometer (SPI)
OSD: BetaFlight OSD w/ AT7456E chip
BEC Output: 5V@2A
Size: 21mm*21mm
Mounting holes: 16mm*16mm
Integrated LC Filter
Input voltage 2-4S LIPO
Firmware target: MATEKF411
Weight: 2.5g
STABLE F411 BLheli_S 4IN1 12A ESC(16*16mm)
MCU: BB21F16G
Continuous current: 12A
Input voltage : 2-4S LIPO
ESC protocol: pwm, oneshot125, multishot, dshot150, 300, 600, etc.
Size: 23mm*21mm
Mounting hole 16*16mm
Firmware target: Blheli_S G_H_30
Current meter: 210
Weight: 2.7g
STABLE F411 VTX 5.8G 200mW(16*16mm)
Power : PIT/25/100/200mW
Antenna interface : IPEX (UFL)
Telemetry: IRC Tramp
Size: 17mm*27mm
Mounting holes: 16*16mm
Integrated LC Filter
Weight: 1.6g
Package Included:
1 x PHANTOM Toothpick Freestyle 2-3S FPV Racing Drone
