Name: Geprc MARK4 225mm 5 Inch / 260mm 6 Inch / 295mm 7 Inch Frame Kit for RC Drone FPV Racing
Price: 51.90 AUD
Availability: InStock
Rating: 4.3 (6 reviews)

Description

Geprc MARK4 225mm 5 Inch / 260mm 6 Inch / 295mm 7 Inch 3K Carbon Fiber Racing Frame Kit

Specification:
Brand Name: Geprc
Model: MARK4
Item Name: 225mm 5 Inch / 260mm 6 Inch / 295mm 7 Inch Frame Kit
Material: Full 3K Carbon Fiber
Wheelbase: 225mm / 260mm / 295mm ( Optional)
Frame Type: H type

Arms Plate Thickness: 5mm

Side Plate Thickness: 2.5mm

Top Plate Thickness: 2.5mm

Bottom Plate Thickness: 2.5mm

Protect Plate Thickness: 2mm

Size: 145*172mm@ 225mm ; 162*203mm@ 260mm ; 193*223mm@ 295mm

Weight: 102g@ 225mm ; 119g@260mm; 121g@ 295mm

Features:

– Super lightweight Freestyle frame

– Beautiful appearance design , durable in crashing

– Quick maintenance Arms and replacement of equipment

– 25mm standoffs for better height and CG relation,Ample space for electronic installation

– Alu6061 Srandoff New , Strengthen the hardness

– There are 30.5*30.5 and 20*20 flight control holes , Stack can fit in the center or the rear.

– High quality 3K twill carbon fiber plate, high precision CNC processing

– YFS screw, 12.9 grade strength, non-slip teeth, anti-rust,Durable steel hardware

225mm 5 Inch Recommended Parts:

Flight Controller: RF/Kiss/F3/F4/F7

Motor: 2205/2206/2207/2207.5/2305/2306

ESC: 30A-50A

Propeller: 5inch

Lipo Battery: 4S 1500mAh ~ 6S 1150mAh

260mm 6 Inch Recommended:

Flight Controller: RF/Kiss/F3/F4/F7

Motor: 2207.5/2305/2306/2407

ESC: 35A-60A

Propeller: 6 inch

Lipo: 4S 1500mAh ~ 6S 1300mAh

295mm 7 Inch Recommended:

Flight Controller: RF/Kiss/F3/F4/F7

Motor: 2207.5/2305/2306/2408/2507

ESC: 40A-60A

Propeller: 7inch

Lipo: 4S 1800mAh ~ 6S 2200mAh

The following Parts are Compatible: ( Not Included)
FC & ESC & VTX: LDARC 30.5×30.5mm F4 FC w/ 25/-600mW VTX & 40A ESC
HGLRC Titan Plus F460 Stack F4 FC & 60A BL_32 4in1 ESC

Brushless Motor: Racerstar & T-Motor F40 II 2305 1600KV 4-6S Brushless Motor
HGLRC Forward 2408 1700KV 6S/ 2500KV 4S Brushless Motor

Propeller: 10 Pairs LDARC 5×4.5×3 5045 5 Inch 3-Blade Propeller CW CCW
Gemfan Flash 6042 6×4.2×3 6 Inch 3-Blade Propeller 2 CW & 2 CCW
2 Pairs DALPROP CYCLONE T7056C 7inch Crystal 3-blade Propeller

Lipo Battery: AHTECH Infinity 4S 14.8V 1500mAh 85C Graphene LiPo Battery XT60
Infinity 22.2V 6S1P 2200mah 70C Graphene Lipo Battery With XT60 Plug

Package Included:
1 x Geprc Mark4 5Inch / 6Inch/ 7Inch Frame

4 x 5*150 Nylon tie

2 x 20*220 GEPRC Lipo strap

1 x 15*250 GEPRC Lipo strap

1 x 2.4G Antenna fixed tube
