Description
Geprc Cygnet CX2 CX3 2 Inch 115mm / 3 Inch 145mm 3mm Arm Carbon Fiber & 7075 CNC Frame Kit
Specification:
Brand Name: Geprc
Model: Cygnet CX2 / CX3
Item Name: 2 Inch 115mm / 3 Inch 145mm Racing Frame Kit
Version: 2 Inch / 3 Inch ( Optional )
Wheelbase: 115mm ( 2 Inch ) ; 145mm ( 3 Inch)
The Thickness of Bottom Plate: 3mm
The Thickness of Top Plate: 3mm
Material: 3K Carbon Fiber & 7075 CNC
Weight: 36g ( 2 Inch ) ; 37g ( 3 Inch)
Recommend Parts: ( Not Included)
| CX2 2 Inch 115mm Frame | Flight Controller: 20x20mm F3 / F4 Flight Controller
Brushless ESC: 10-20A ESC Brushless Motor: 1104/ 1105/ 1106/ 1107 Motor Propeller: 2 Inch Prop Lipo Battery: 2S 550mAh – 3S 650mAh Lipo |
| CX3 3 Inch 145mm Frame | Flight Controller: 20x20mm F3 / F4 Flight Controller
Brushless Motor: 1106 /1107/1108/1205/1206 Motor Brushless ESC: 15-28A Propeller: 3 Inch Lipo Battery: 3S 550mAh – 4S 650mAh |
The following parts are compatible:
Flight Controller & ESC & VTX Stack:
Geprc Stable Stack 20A BL_S ESC & Omnibus F4 FC & 48CH 25/100/200mW VTX
Brushless Motor:
HGLRC Flame HF1106 1106 6000KV 2-3S Motor
Geprc GR1206 4500KV 2-3S Brushless Motor
Propeller:
Dalprop Cyclone Q2035C 2035 4-blade Propeller CW & CCW
Emax AVAN Mini 3 Inch 3X2.4X3 3-blade Propeller CW & CCW
Camera:
RunCam Split Mini 2 1080P/60fps HD Recording & WDR FPV Camera N/P
Lipo Battery:
Gaoneng GNB 11.1V 550mAh 80/160C 3S Lipo Battery XT30 Plug
CNHL MiniStar 650mAh 14.8V 4S 70C Lipo Battery XT30U Plug
Package Included:
1x Geprc CX2 2 Inch 115mm Frame Kit
OR
1x Geprc CX3 3 Inch 145mm Frame Kit
