Description
FuriousFPV F-35 Lightning Flight Controller + AirSpeed Sensor + GPS Module + bluetooth Module
Description:
Furious FPV F-35 Lightning FC – Elevate Your Horizons.
Step into the all new F-35 Lightning FC – Furious FPV's 1st dedicated wing flight controller, ready and waiting to open all new worlds to winged FPV.
Encompassed by a robust case for maximum levels of protection and strength, the F-35 FC offers the ultimate levels of FPV capability that is dedicated & purpose built for the demands and capabilities of FPV winged flight.
Ultra easy to install with a massively powerful MCU STM F4 micro controller, the F-35 Lightning FC supports a full (6) UART's for GPS, VTX Control, S.PORT Telemetry,
Crossfire RX, RX, bluetooth functionality. With these systems in play, the F-35 offers worlds of capability & performance for maximum levels of FPV flight.
Integrating a built in 5V@3A BEC, buzzer port, anti vibration silicone dampeners and battery monitor with current sensor, the F-35 Lightning FC packs a massive punch in an ultra compact form. Pair this with a built in Barometer & OSD system, the F-35 FC is the game changing flight controller that is ready for anything and everything a pilot could possibly desire.
Take your winged FPV flight to new worlds and beyond with the Furious FPV F-35 Lightning FC – the ultimate winged FPV flight control system.
Specifications:
Brand Name: FuriousFPV
Item Name: F-35 Lightning Flight Controller Full Option
Item NO.: FPV-F35-H
Specifications of AirSpeed Sensor:
Brand Name: FuriousFPV
Item Name: AirSpeed Sensor
Item NO.: FPV-0369-S
Power Input: 5V
Output Voltage: 0 to 5V
Sensor Type: Analog
Dimension: 27x21x10.5mm
Weight: 3.6g
Application: Optimize for F-35 Lightning FC
Pressure Range: -2 to 2 kPa (-0.3 to 0.3 psi)
Specifications of bluetooth Module:
Brand Name: FuriousFPV
Item Name: bluetooth Module
Item NO.: FPV-0358-S
Power Input: 3.3V
Protocol: BLF V4.0
Dimension: 15x19x5.5mm
Weight: 1.3g
Working Range: 30m
Working Frequency: 2.4GHz
Specifications of GPS Module:
Brand Name:
Item Name:
Item NO.:
Features: GPS+GLONASS
Position Accuracy: 2m
Sensitivity: -160dBm/-167dBm
Update Rate: 1Hz default,up to 10Hz
Baudrate: 57600
Dimension: 18.6×20.2×7.1mm
Weight: 8.4g
Application: Optimize for F-35 Lightning FC
Features:
• Flight controller 6 DOF + 30 DOF MAG
• MCU STM F4 high performance
• Built-in OSD
• Support up to 6 UARTs (GPS, VTX Control, S.PORT Telemetry, Crossfire RX, RX, bluetooth)
• Support 2 motors and 4 servos
• Built-in Driver Inverter for SBUS and S.PORT connections
• Built-in Battery Voltage and Current monitor
• Camera and VTX port built-in Peripheral pass
• Built-in 5V@3A BEC for small Digital servos, can be easily changed to External BEC for bigger Servos
• Built-in Buzzer port
• High quality silicone wires with optimized lengths are included
• Support INAV firmware
• Vertical USB ports and pads, easy to install
Spare Airspeed Sensor, Click Here
Spare bluetooth Module, Click Here
Spare GPS Module, Click Here
Spare F-35Lightning FC
, Click HereSpare Airspeed Sensor, Click Here
Spare bluetooth Module, Click Here
Spare GPS Module, Click Here
English Manual for F-35 Lightning FC, Click Here
Package Included:
1x F-35 Lightning FC
1x AirSpeed Sensor
1x bluetooth Module
1x GPS Module
,
,
