Description
Specification:
Brand Name: FullSpeed
Item Name: 4K TurboWhoopFrame Wheelbase: 100mm
Thickness of bottom plate: 2mm
Thickness of side plate: 1.5mm
Weight:110g(without battery)
Flight controller: FSD428 F411 Flight controller built-in OSD
ESC: FSD428 28A ESC BLHELI_S 2-4S 4in1 ESC Dshot600
Motor: 1104 5500kv
Propeller: 1935 5-blade propeller
Camera: Caddx.us Tarsier 4K 1200TVL Dual Lens
VTX: FSD TX600 Pit/25/100/200/400/600 switchable VTX(support IRC Tramp)
FullSpeed FSD428 F411 Flight controller
Size: 27.5mm * 27.5mm * 5mm
Mounting hole: 20mm * 20mm
MCU: STM32 F411
Firmware: FULLSPEEDF411 Betaflight
BEC: 5V/3A
Input Voltage: 2-4S
Built-in Betaflight OSD
FullSpeed FSD482 28A BLHELI_S 4in1 ESC
Size: 27mm * 27mm * 5mm
Mounting hole: 20mm * 20mm
Firmware: BLHELI_S
Input voltage: 2-4S
Continuous current: 28A
BEC Ouput: NO
FullSpeed FSD TX600 25mW-600mW VTX FPV Transmitter
Output power: PIT/25mW/100mW/200mW/400mW/600mW switchable
Control mode:BFOSD control(support IRC Tramp)/button
Video system: NTSC/PAL
Antenna: IPEX
BAT: 5V Recommended
Frequency: 5.8GHz 6 bands 48 channels, with Raceband: 5362-5945 MHZ
(TX600's factory set up is on lock mode(5733-5866MHZ unlock). Please follow your local laws and regulations
if you need to unlock the frequency.)
Size: 26*26mm(L*W),Hole:20*20mm
Weight: 2.3g
Package Include(BNF include receiver)
1 x 4K TurboWhoop frame kit
1 x FSD428 2-4S 28A Flight tower
4 x 1104-5500KV brushless motor
2 x 1935 5-blade propeller(CW)
2 x 1935 5-blade propeller(CCW)
1 x Caddx.us Tarsier 4K 1200TVL Dual Lens
1 x FSD TX600 25mW-600mW VTX FPV Transmitter
