Description
FLYWOO Vampire 230mm 5 Inch FPV Racing Frame Kit 5mm Arm Supports Foxeer Monster Mini Pro
Description:
Brand: FLYWOO
Item Name: Vampire 230mm Frame Kit
Wheel base: 230mm
Size: Size: front width140mm/back width175mm
Material: 100% 3K carbon fiber
Thickness of arms: 5mm
Thickness of top plate: 2mm
Thickness of bottom plate: 2mm
Weight: 70g
Recommend parts (package doesn't include):
Brushless motor: 2204/2205/2206
Brushless ESC: 20A-30A
Flight controller: F3 / F4 ( 30.5*30.5mm)
Camera: Foxeer Monster Mini Pro / Foxeer Predator Mini / Foxeer Predator V3 / Foxeer Arrow Mini Pro (width: 21.8*21.8mm)
Battery: 14.8V 4S 1500mah
Propeller: 5 inch
The following products in our website are suitable for this 230mm racing frame:
Brushless motor: Racerstar BR2205 2300KV 2-4S Motor Or Racerstar SPROG X 2206 2300KV 3-4S Motor
Brushless ESC: Racerstar RS20Ax4 4 in 1 Blheli_S ESC Or Racerstar RS30A Blheli_S 2-4S ESC
Flight controller: F3 Acro 6 DOF/Deluxe 10 DOF Or F4 AIO OSD 5V BEC Current Sensor
Brushless motor: Racerstar BR2205 2300KV 2-4S Motor Or Racerstar SPROG X 2206 2300KV 3-4S Motor
Brushless ESC: Racerstar RS20Ax4 4 in 1 Blheli_S ESC Or Racerstar RS30A Blheli_S 2-4S ESC
Flight controller: F3 Acro 6 DOF/Deluxe 10 DOF Or F4 AIO OSD 5V BEC Current Sensor
Or Racerstar StarF3S 30A BL_S 4 In 1 ESC w/ F3 AIO OSD BEC Current Sensor
Lipo battery: AHTECH Infinity 4S 14.8V 1500mAh 85C Graphene Or Eachine 4S 14.8V 1500mAh 75C Or Gaoneng GNB 14.8V 1500mAh 4S 120C/240C
5 inch propeller: DALPROP T5045C Cyclone Or LDARC 5045 3-Blade Or Racerstar Fish Bone 5041 3 Blade
Lipo battery: AHTECH Infinity 4S 14.8V 1500mAh 85C Graphene Or Eachine 4S 14.8V 1500mAh 75C Or Gaoneng GNB 14.8V 1500mAh 4S 120C/240C
5 inch propeller: DALPROP T5045C Cyclone Or LDARC 5045 3-Blade Or Racerstar Fish Bone 5041 3 Blade
Package included:
1 x Vampire 230mm frame kit
1 x 20mm*200mm battery strap
