Description
FLYWOO INI 45A 4 IN 1 Blheli_32 2-6S DSHOT1200 Brushless ESC Support Telemetry for RC Drone FPV Racing
Specification:
Brand Name: FLYWOO
Model: INI 45A
Item Name: 50A BLheli_32 2-6S 4in1 Brushless ESC
Version: Gold Version/Titanium Version
Peak Current: 55A
Input Voltage: 2-6S
Firmware: BLheli_32
BEC: NO
Weight: 18g (including heatsink)
Mounting Hole: 30.5×30.5mm ( M3)
Feature:
– Include one pc 35V 470uf Capacitor.
– Better to use with flywoo series Flight Controller.
– Support Telemetry/Current Meter
– Support Oneshot, Multishot, DShot150/300/600 and DShot1200
Notice:
8 Pin from left to right, GND, BAT, M1, M2, M3, M4, CUR, TX
Therefore, if using other fc, pls double check whether if its' connector is compatible.
Package Included:
1x 45A 4 in 1 Brushless ESC
1x Capacitor
1x 8pin Connector Cable
1x bag of Screws
