Description
DJI Mavic 2 Pro / Zoom 8KM 1080P FPV w/ 3-Axis Gimbal 4K Camera Omnidirectional Obstacle RC Drone
Introducing the DJI Mavic 2
Specifications:
Mavic 2 Pro Camera |
Sensor | 1” CMOS Effective Pixels: 20 million |
| Lens | FOV: about 77° 35 mm Format Equivalent: 28 mm Aperture: f/2.8–f/11 Shooting Range: 1 m to ∞ |
|
| ISO Range | Video: 100-6400 Photo: 100-3200 (auto) 100-12800 (manual) |
|
| Shutter Speed | Electronic Shutter: 8–1/8000s | |
| Still Image Size | 5472×3648 | |
| Still Photography Modes | Single shot Burst shooting: 3/5 frames Auto Exposure Bracketing (AEB): 3/5 bracketed frames at 0.7 EV Bias Interval (JPEG: 2/3/5/7/10/15/20/30/60s RAW:5/7/10/15/20/30/60s) |
|
| Video Resolution | 4K: 3840×2160 24/25/30p 2.7K: 2688×1512 24/25/30/48/50/60p FHD: 1920×1080 24/25/30/48/50/60/120p |
|
| Max Video Bitrate | 100Mbps | |
| Color Mode | Dlog-M (10bit), support HDR video (HLG 10bit) | |
| Supported File System | FAT32 (≤ 32 GB) exFAT (> 32 GB) |
|
| Photo Format | JPEG / DNG (RAW) | |
| Video Format | MP4 / MOV (MPEG-4 AVC/H.264, HEVC/H.265) | |
Mavic 2 Zoom Camera |
Sensor | 1/2.3" CMOS Effective Pixels: 12 million |
| Lens | FOV: about 83° (24 mm); about 48° (48 mm) 35 mm Format Equivalent: 24-48 mm Aperture: f/2.8 (24 mm)–f/3.8 (48 mm) Shooting Range: 0.5 m to ∞ |
|
| ISO Range | Video: 100-3200 Photo: 100-1600 (auto) 100-3200 (manual) |
|
| Shutter Speed | Electronic Shutter: 8–1/8000s | |
| Still Image Size | 4000×3000 | |
| Still Photography Modes | Single shot Burst shooting: 3/5/7 frames Auto Exposure Bracketing (AEB): 3/5 bracketed frames at 0.7 EV Bias Interval (JPEG: 2/3/5/7/10/15/20/30/60s RAW:5/7/10/15/20/30/60s) |
|
| Video Resolution | 4K: 3840×2160 24/25/30p 2.7K: 2688×1512 24/25/30/48/50/60p FHD: 1920×1080 24/25/30/48/50/60/120p |
|
| Max Video Bitrate | 100Mbps | |
| Color Mode | D-Clinelike | |
| Supported File System | FAT32 (≤ 32 GB) exFAT (> 32 GB) |
|
| Photo Format | JPEG / DNG (RAW) | |
| Video Format | MP4 / MOV (MPEG-4 AVC/H.264, HEVC/H.265) | |
Aircraft |
Takeoff Weight | Mavic 2 Pro: 907 g Mavic 2 Zoom: 905g |
| Dimensions | Folded: 214×91×84 mm (length×width×height) Unfolded: 322×242×84 mm (length×width×height) |
|
| Diagonal Distance | 354 mm | |
| Max Ascent Speed | 5 m/s (S-mode) 4 m/s (P-mode) |
|
| Max Descent Speed | 3 m/s (S-mode) 3 m/s (P-mode) |
|
| Max Speed (near sea level, no wind) | 72 kph (S-mode) | |
| Max Service Ceiling Above Sea Level | 6000 m | |
| Max Flight Time (no wind) | 31 minutes (at a consistent 25 kph) | |
| Max Hovering Time (no wind) | 29 minutes | |
| Max Flight Distance (no wind) | 18 km (at a consistent 50 kph) | |
| Max Wind Speed Resistance | 29–38 kph | |
| Max Tilt Angle | 35° (S-mode, with remote controller) 25° (P-mode) | |
| Max Angular Velocity | 200°/s | |
| Operating Temperature Range | -10°C – 40°C | |
| Operating Frequency | 2.400 – 2.483 GHz 5.725 – 5.850 GHz |
|
| Transmission Power (EIRP) | 2.400 – 2.483 GHz FCC: ≤26 dBm CE: ≤20 dBm SRRC: ≤20 dBm MIC: ≤20 dBm 5.725-5.850 GHz |
|
| GNSS | GPS+GLONASS | |
| Hovering Accuracy Range | Vertical: ± 0.1 m (when vision positioning is active) ± 0.5 m (with GPS positioning) Horizontal: ± 0.3 m (when vision positioning is active) ± 1.5 m (with GPS positioning) |
|
| Internal Storage | 8 GB | |
Gimbal |
Mechanical Range | Tilt: -135–45° Pan: -100–100° |
| Controllable Range | Tilt: -90–30° Pan: -75–75° |
|
| Stabilization | 3-axis (tilt, roll, pan) | |
| Max Control Speed (tilt) | 120° /s | |
| Angular Vibration Range | ±0.01° (Mavic 2 Pro) ±0.005° (Mavic 2 Zoom) |
|
Sensing System |
Sensing System | Omnidirectional Obstacle Sensing |
| Forward | Precision Measurement Range: 0.5 – 20 m Detectable Range: 20 – 40 m Effective Sensing Speed: ≤ 14m/s FOV: Horizontal: 40°, Vertical: 70° |
|
| Backward | Precision Measurement Range: 0.5 – 16 m Detectable Range: 16 – 32 m Effective Sensing Speed: ≤ 12m/s FOV: Horizontal: 60°, Vertical: 77° |
|
| Upward | Precision Measurement Range: 0.1 – 8 m | |
| Downward | Precision Measurement Range: 0.5 – 11 m Detectable Range: 11 – 22 m |
|
| Sides | Precision Measurement Range: 0.5 – 10 m Effective Sensing Speed: ≤ 8m/s FOV: Horizontal: 80°, Vertical: 65° |
|
| Operating Environment | Forward, Backward and Sides: Surface with clear pattern and adequate lighting (lux > 15) Upward: Detects diffuse reflective surfaces (>20%) (walls, trees, people, etc.) Downward: Surface with clear pattern and adequate lighting (lux > 15) Detects diffuse reflective surfaces (>20%) (walls, trees, people, etc.) |
|
Remote Controller |
Operating Frequency | 2.400 – 2.483 GHz; 5.725 – 5.850 GHz |
| Max Transmission Distance (unobstructed, free of interference) |
2.400 – 2.483 GHz; 5.725 – 5.850 GHz FCC: 8000 m CE: 5000 m SRRC: 5000 m MIC: 5000 m |
|
| Operating Temperature Range | 0℃ – 40℃ | |
| Transmission Power (EIRP) | 2.400 – 2.483 GHz FCC: ≤26 dBm CE: ≤20 dBm SRRC: ≤20 dBm MIC: ≤20 dBm 5.725-5.850 GHz |
|
| Battery | 3950 mAh | |
| Operating Current/Voltage | 1800 mA ⎓ 3.83 V | |
| Supported Mobile Device Size | Max length: 160 mm; max thickness: 6.5–8.5 mm |
|
| Supported USB Port Types | Lightning, Micro USB (Type-B), USB-C | |
APP |
Video Transmission System | OcuSync 2.0 |
| Name | DJI GO 4 | |
| Live View Quality | Remote Controller: 720p@30fps / 1080p@30fps DJI Goggles: 720p@30fps / 1080p@30fps DJI Goggles RE: 720p@30fps / 1080p@30fps |
|
| Latency (depending on environmental conditions and mobile device) | 120 – 130 ms | |
| Max Live View Bitrate | 40Mbps | |
| Required Operating System | iOS 9.0 or later Android 4.4 or later | |
Intelligent Flight Battery |
Capacity | 3850 mAh |
| Voltage | 15.4 V | |
| Max Charging Voltage | 17.6 V | |
| Battery Type | LiPo 4S | |
| Energy | 59.29 Wh | |
| Net Weight | 297 g | |
| Charging Temperature Range | 5℃ – 40℃ | |
| Max Charging Power | 80 W | |
Charger |
Input | 100-240 V, 50/60 Hz, 1.8A |
| Output | Main: 17.6 V ⎓ 3.41 A or 17.0 V ⎓ 3.53 A USB: 5 V⎓2 A |
|
| Voltage | 17.6 ± 0.1 V | |
| Rated Power | 60 W | |
Supported SD Cards |
Supported SD Cards | Micro SD™ Supporting Micro SD with capacity up to 128 GB and R/W speed up to UHS-I Speed Grade 3 |
Package Included:
1 x Aircraft
1 x Remote Controller
1 x Intelligent Flight Battery
1 x Charger
1 x Power Cable
6 x Propeller
3 x RC Cable (Lightning, Standard Micro USB, USB Type-C)
1 x Gimbal Protector
1 x Communication Cable (USB3.0 Type-C)
1 x USB Adapter
3 x RC Cable Slider (1 large, 2 small)
2 x Spare Control Sticks
