Description
Caddx Turbo Micro F2 1/3" CMOS 2.1mm 1200TVL 16:9/4:3 NTSC/PAL Low Latency FPV Camera
Description:
| Model | Turbo Micro F2 |
| Image Sensor | 1/3" COMS Sensor |
| Horizontal Resolution | 1200 TVL |
| TV System | NTSC/PAL changeable |
| Image | 16:9/4:3 |
| WDR | D-WDR |
| Min, Illumination | 0.001Lux@F1.2 |
| Lens | 2.1mm lens |
| Synchronization | Internal |
| Electronics Shutter | PAL:1/50~100,000; NTSC:1/60~100,000 |
| S/N Ratio | >52dB (AGC OFF) |
| Video Output | CVBS |
| Audio | YES |
| Auto Gain Control | YES |
| BLC | YES |
| Camera OSD | YES |
| DNR | 2 DNR |
| Language | ENG/CHN |
| Image Flip | Support |
| Day/Night | Auto/Color/B&W |
| Dimension | 19mm*19mm*19mm |
| Wide Power Input | DC 4.5-40V |
| Work Temperature | -20℃~+60℃ |
| Work Humidity | 20%~80% |
| Weight | 5.5g (N.W.) |
| Color | Yellow/Green/Pink/Black |
Compare with other camera:
Daytime (Caddx on left ):
Night(Caddx on Left ):
Caddx Micro Turbo F2 manual, click here
Package included:
1 x Caddx Turbo Micro F2 FPV Camera
1 x Aluminum bracket
1 x FPV silicone cable (4-pin port one side, 3-pin port the other side)
1 x Internal hexagonal wrench
1 x Warranty card
1 set x Screws
1 set x Screws
