C-Fly DREAM GPS WIFI FPV With 2-Axis Gimbal 1080P HD Camera Optical Flow RC Drone Quadcotper RTF
Specifications:
Aircraft |
Size | 148 X 145 X 60 mm (L x W x H) |
| Wheelbase | 175mm | |
| Weight (Battery & Propellers Included) | 248g | |
| Motor | 18*12mm 1900KV | |
| Max Ascent Speed | 2m/s | |
| Max Descent Speed | 1.5m/s | |
| Max Speed | 20km/h | |
| Max Service Ceiling Above Sea Level | 3000m | |
| Max Flight Time | 15mins | |
| Max Total Travel Distance | 3km | |
| Operating Temperature Range | 0~40° | |
| Satellite Positioning Systems | GPS/GLONASS | |
| Hover Accuracy Range | Vertical: +/- 0.5 m Horizontal: +/- 0.5 m (when Optical flow is active): +/- 1.0m |
|
| Operating Frequency | FCC: 5.150-5.250GHZ CE: 5.150-5.250GHz |
|
| Transmitter Power (EIRP) | 5.2GHz FCC:<=23dBm | |
Optical flow system |
Optical Flow System | yes |
| Operating Environment | Surface with clear pattern and adequate lighting (lux >15) | |
| Velocity Range | ≤1.5 m/s at 6.6 ft (2 m) above ground | |
| Altitude Range | 0.5~5m | |
Gimbal |
Controllable Range | Pitch: -90°~0° |
| Stabilization | 2-axis (pitch |
|
Camera |
Sensor | 1/2.7"CMOS |
| Lens | FOV 110° 42 mm (35 mm format equivalent) | |
| ISO Range | Video: 100 – 3200 Photo: 100 – 1600 |
|
| Image Size | 2560*1440 | |
| Video Recording Resolution | FHD: 1920*1080 | |
| Supported File Systems | FAT32 (<=32GB) | |
| Photo | JPEG | |
| Video | MP4 | |
| Supported SD Cards | Micro SD Max capacity: 32GB. Class 10 or UHS-1 rating required |
|
| Operating Temperature Range | 0~40° | |
Live View |
Mobile App | C-Fly |
| Live View Quality | 720p | |
| FPV Transmission Distance | 800m | |
| Required Operating Systems | iOS 9.0 or later Android 4.4 or later | |
WiFi |
Operating Frequency | 5G |
| Max Transmission Distance | Horizontal: 200m Vertical: 150m |
|
| Max Speed | 20 km/h | |
| Max Ascent Speed | 2 m/s | |
| Max Descent Speed | 1 m/s | |
Battery |
Capacity | 1000 mAh |
| Voltage | 11.4V | |
| Battery Type | LiPo 3S | |
| Energy | 10.83 Wh | |
| Net Weight | about 72g | |
| Charging Temperature Range | 5~40° | |
| Max Power | 15W | |
Charger |
Voltage | 12.6V |
| Rated Power | 18W | |
Remote Controller (RTF) |
Operating Frequency | 5GHz |
| Max Transmission Distance | 800m | |
| Operating Temperature Range | 0~40° | |
| Transmitter Power (EIRP) | FCC: <=26dBm CE: <=20dBm SRRC: <=20dBm |
|
| Operating Current/Voltage | 1.5A@3.7V | |
| Supported Mobile Device Size | Thickness Supported: 6.5-8.5mm Max length: 80mm |
|
| Port Types | Micro USB | |
| Charge | USB port | |
| Max Charging Power | 5w | |
Battery of Remote Controller (RTF) |
Capacity | 2600mAh |
| Voltage | 3.7V | |
| Battery Type | LiPo 18650 1S | |
| Energy | 9.62Wh | |
| Net Weight | about 60g | |
| Operating Temperature Range | 5~40° |
Features:
– Small total weight is 248g, with a new vision 2-axis gimbal, easy to carry, easy to shoot.
– Precision hover, bulit-in GPS+Glonass system,make the drone stable.
– With advanced Optical flow system, it has better adaptability to all kinds of ground textures.
– With 2-axis gimbal, pitch angle 0°-90°,720P FPV, 1080P high quality video.guarantee a perspective and unique image.
– One key take off/landing. Humanized design,more intelligent flight.
– One key return, will return automatically, make everything simple.
– Dream can fly 15mins, control distance is about 800m.
– Waypoints function, Follow me mode, Fly around mode.
– Low battery protection, flight control fail-safe.
Package Included:
1 x C-Fly Dream Quadcopter
1 x 1080P Camera
1 x 2-Axis Gimbal
1 x Transmitter (BNF Version Not Included)
1 x 11.4V 1000mAh Lipo Battery
2 x Propeller
1 x Charger
1 x Tranmitter Battery (BNF Version Not Included)
1 x Tranmitter USB Charging Cable
1 x Manual
