Description
Boscam SKY FPV 5.8GHz Petals Clover Mushrooms Antenna RP-SMA Male is now selling in our US warehouse with fast delivery
Boscam SKY FPV 5.8GHz Petals Clover Mushrooms Antenna RP-SMA Male
Specification:
Product: Cloud Spirit Antennas(TxA and RxA, a pair in one set)
TxA is a circular-polarized omni antenna with three lobes
RxA is a circular-polarized omni antenna with four lobes
Gain:TxA 1.1dBi
RxA 1.4dBi
SWR: 1.2.:1, Tuned for 5645-5945Mhz
Polarization:RHCP,Right Hand Circular Polarization
Connector:Straight SMA
Length: TxA 78.5mm
RxA 98.8mm
Weight: TxA10.3g
RxA 11.5g
Package Size: 135mm*85mm*45mm
Package Weight: 63.3g
Feature:
Greatly Increase Range and All Direction Reception
Boscam makes good quality FPV System, they want them to work even better so they made this Cloud Spirit Antenna. Inside the
mushroom, Tx side splits at 120 degrees and Rx side splits at 90 degrees, don't put them on the wrong side! Both are designed to cover full 360 degrees, so you don't get any blind spot in the sky. They look a bit strange, but the clover leaf design really solve problems like we have on old TVs, like color shift and double vision… if you were using the ordinary black antenna and having those problems, try this mushroom, it makes a huge difference! Besides, this design increase efficiency of the system, you will get longer range than those single antennas.
Package Included:
1 x TxA Petals Clover Mushrooms Antenna
1 x RxA Petals Clover Mushrooms Antenna
