Description
Specifications:
Center frequency: 5.8 GHz
Bandwidth: 700 MHz (5.3– 6 GHz)
Matching: S11 < -20 dB,
VSWR < 1.5 (at center frequency)
Axial ratio: < 1.3
Antenna gain: 8 dBi
Half power beam width: 55° (horizontal and vertical)
Radiation efficiency: 83.5%
Extension cable length:80mm
size: 60x60x22mm
weight :15g
Features:
1.The red one is RP-SMA-Male.
2.The blue one is SMA Male.
Package included:
1 x Aomway ANT018 FPV Pagoda Antenna
