Description
Description
Length: 935mm
Height: 259mm
Width: 151mm
Main Blade Length: 470mm
Main Rotor Diameter: 1054mm
Tail Rotor Diameter: 219mm
Motor Pinion Gear: 12T
Main Drive Gear: 134T
Main Drive Pulley: 80T
Tail Drive Gear: 21T
Drive Gear Ratio: 11.17:1:3.81
Weight(w/o battery): approx. 1450g
Package Weight: About 2696g
Radio transmitter and electronic equipment required for assembly:
Transmitter(6-channel or more, helicopter system)
Receiver(6-channel or more)
6S Li-Po 2600 ~ 3300mAh (3300mAh suggestion)
Digital Pitch Gauge
Standard equipment
Microbeast PLUS Flybarless System x 1 set
RCE-BL80X Brushless ESC x 1
520MX Brushless Motor(1600KV/3527) x 1
DS530M Digital servo x 3
DS535M Digital servo x 1
Package
T-REX 500X KIT Set x 1
Microbeast PLUS Flybarless System x 1 set
470 Carbon Fiber Blades x 1
78 Tail Rotor Blade x 1
520MX Brushless Motor(1600KV/3527) x 1
DS530M Digital servo x 3
DS535M Digital servo x 1
RCE-BL80X Brushless ESC x 1
,
,
,
,
,
,
,
