AlfaRC Fighter 230mm 260mm 290mm 5/6/7 Inch Carbon Fiber FPV Freestyle Stretch X Frame kit for RC Drone
Specification:
Brand name: AlfaRC
Item name: Fighter Frame Kit
Brand name: AlfaRC
Item name: Fighter Frame Kit
Wheelbase:230mm(5inch)/260mm(6inch)/290mm(7inch)
Arm Plate Thickness: 230mm(4MM)/260mm(4MM)/290mm(5MM)
Bottom Plate Thickness: 2mm
Upper Plate Thickness: 2mm
Side plate thickness: 2mm
Height of aluminum column:30mm
Camera angle range: 0-70°
Material: 3K Carbon Fiber
Material: 3K Carbon Fiber
Weight: 102g
Recommend Parts(Not included):
Brushless motor: EMAX RSII 2306 or DYS Samguk Series Shu 2306 or Racerstar BR2306S 2400KV
Brushless ESC: Racerstar REV35 BLheli_S 3-6S 4 In 1 or DYS Aria BLHeli_32bit 35A or Holybro Tekko32 35A BLHeli_32 or DALRC ENGINE 40A 3-5S Blheli_32 4 in 1
Flight controller:30.5mm hole F3 Acro 6 DOF/Deluxe 10 DOF Or F4 AIO OSD 5V BEC Current Sensor
ESC & FC flytower: MAMBA F405 F40 40A 3-6S DSHOT600 Brushless ESC
Brushless ESC: Racerstar REV35 BLheli_S 3-6S 4 In 1 or DYS Aria BLHeli_32bit 35A or Holybro Tekko32 35A BLHeli_32 or DALRC ENGINE 40A 3-5S Blheli_32 4 in 1
Flight controller:30.5mm hole F3 Acro 6 DOF/Deluxe 10 DOF Or F4 AIO OSD 5V BEC Current Sensor
ESC & FC flytower: MAMBA F405 F40 40A 3-6S DSHOT600 Brushless ESC
Propeller: 5-7inch.
Camera: 28mm install hole
Camera: 28mm install hole
Battery: 3/6S 1300-2200mAh Lipo Battery
Features:
Quick disassembly design
4-5MM independent arm, fast demolition, unique design virtual bit less
We also designed a fixed four arm of the aluminum alloy, so that the arm is not easy to shift.
exquisite design,X structure, suitable for racing with Freestyle fancy flight
High quality 3K full carbon fiber board, high precision CNC aluminum alloy parts, simple structure and strong
The arm is at the narrowest point of 14mm, the wind resistance is smaller, but more commuted arm, easy to maintain
The position of the motor compartment is widened and the collision is not easy to hit the motor
Machine all use 12.9 strength YFS screws
support Mainstream FPV camera and Mini Series FPV camera,and other lenses
Package Included:
1 x Frame Kit
1 x Frame Kit
