Description
Oscar's Backpack VTX Support Smart Audio, the hole position of OBVTX compatible with RunCam Micro Swift 3,
RunCam Micro Swift 2 and RunCam Micro Eagle, not compatible with Foxeer cameras.
RunCam Micro Swift 2 and RunCam Micro Eagle, not compatible with Foxeer cameras.
Specification:
Input voltage: 5V
Extra feature: Smart Audio/MIC
Power supply: 5v camera@under 0.3A max
Output power: 25mW/200mW switchable
Antenna connector: MMCX
Cable connector: solder pads
Dimension(with mounting hole): 19*19mm
Weight: 2.8g(excluding antenna)
Antenna connector: MMCX
Cable connector: solder pads
Dimension(with mounting hole): 19*19mm
Weight: 2.8g(excluding antenna)
Features:
Support Pit Mode
25mW and 200mW switchable
One button frequency and power setup
OSD configuration using smart audio
5V to camera @ under 300mA
Package included:
1 x AKK Smart Audio Stackable Backpack FPV Transmitter VTX for Runcam Micro and Foxeer Micro with MIC
1 x MMCX to SMA pigtail
1 x AKK Smart Audio Stackable Backpack FPV Transmitter VTX for Runcam Micro and Foxeer Micro with MIC
1 x MMCX to SMA pigtail
