Description
Specifications:
Brand Name: 3BHOBBY
Item No.: 2408 PROII
KV: 1900/2500
No.of Cells(Lipo): 6S/4S
Stator Diameter: 24mm
Stator Height: 8mm
Shaft Diameter: 5mm
Motor Dimension (Dia.*Len): Φ29.2*32.1mm
Weight(g): 39g(Excluding Cable)
Wire Szie: 18AWG 150mm
Suggested Propeller: 6-7’’
Recommend ESC: 50-60A
Frame Size: 200-250mm
Features:
1. Special designed for long-range flight and great efficiency requirement conditions.
2. Best for 6-7’’ quadcopters
3. Enhanced structure, assured durability. survives greatly under extreme racing conditions
4. Reduced vibration &noise, prolonged bearing life cycle with the new patent wave washer.
5. Continuing our major strength on magnet field optimizing and stator lining. maximum improving efficiency and power.
6. Wire quality assured with one appointed brand only
7. Max thrust up to 2300g+
8. Top material: imported Japanese NSK bearing, Japanese Kawa saki 0.15mm stator, N52H NdFeB magnet, US standard GR5 Titanium hollow shaft
Package Include:
1 X 2408 PROII Motor
2 X M5 7075 Aluminum nut
5 X M3*10 Round head hex socket screws
