Description
16x16mm FullSpeed TeenyF4 F4 MPU6000 1-2S Flight Controller Integrated with OSD for RC Drone
Specification:
Brand Name: FullSpeed
Model: TeenyF4
Item Name: F4 1-2S Flight Controller Integrated with OSD
Processor: STM32F411
Sensor: MPU-6000 (connected by SPI)
Input Voltage: 1-2S Lipo or 1- 2S HV Lipo
Size: 20*20mm
Mounting Hole: 16*16mm
Mount Hole Diameter: 2mm
Weight: 1.9g
Features:
-Support programmable LED Strip (turn off transponder before using)
-Support BLheli/BLHELI_S suite Pass-through ready
-Support PPM,Oneshot125, Oneshot42, Multishot, Dshot150, Dshot300, Dshot600
-Built-in voltage detection, alarm
-Built-in Betaflight-OSD , Configure by Betaflight GUI
-Buzzer Ready (Solder pin)
-LED_STRIP Ready (Solder pin)
Package Included:
1x TeenyF4 flight controller board
1x 6Pin Cable
4x M2*5+5 Nylon column
4x M2 Nuts
